Saturday, March 21, 2009

Feathers, Fuzz, and all that Fluff

Feathered non-avian dinosaurs are nothing new. Sinosauropteryx was the first non-avian feathered dinosaur found, in 1996. As a compsognathid, Sinosauropteryx pushes the origin of avian feathers back near the base of the Coelurosauria, a fact which predicts that certain other theropod lineages will also have feathers. And for the most part, these predictions have come true. Dilong is usually thought to be a basal tyrannosauroid*, Beipiaosaurus is a basal therizinosaur, Caudipteryx and Protarchaeopteryx are basal oviraptorosaurs, Jinfengopteryx is a troodontid, and there are a wealth of feathered dromaeosaurs, including Microraptor and Sinornithosaurus. I don’t really know how scansoriopterygians shake out, but they had feathers, too. As more fossils were unearthed, it became clear that feathers come in a wide range of shapes and types. Most non-avian theropods had what I call “baby chicken” feathers—simple shafts which mat together and probably had an insulatory function (as they do in baby chickens). Then, there are “tuft” feathers, in which a multitude of filaments arise from a single point. Think of these as feathers without quills. The next step seems to be quilled feathers lacked individual barbules, so the feathers are frayed and fluffy, like the downy feathers of many waterbirds. Finally, you get a true “modern” feather—one with a quill and branches with barbules that slide together to give rigidity the structure. Only oviraptorosaurs and paravians have true feathers, and only paravians have asymmetrical feathers—those used for flight. So feather evolutions seems to have followed a fairly straight path, from insulating structures (basal coelurosaurs) to display structures (oviraptorosaurs, paravians, scansoriopterygians) to aerodynamic assists (paravians).

Two fairly recent finds have cast doubt on this linear progression of feather evolution. First, a few years ago, a Chinese specimen of Psittacosaurus turned up with absolutely wonderful soft-tissue details preserved, including incredible skin impressions, an “outline” detailing the body’s overall shape, and—most importantly—long, bristly quills erupting from along the dorsal surface of the tail. These quills are circular in cross-section and appear to be hollow. They are not as tightly packed-together as theropod integument, but they are definitely numerous. I was instantly reminded of porcupine quills, although those of the parrot lizard curve gently back. The second find was a new specimen of Beipiaosaurus published earlier this year. It's "feathers" are roughly similar to the parrot lizard in being long, unbranched "quills," although while those of Psittacosaurus are hollow, cyndrical shafts, Beipiaosaurus' quills seem to be flatter. At any rate, Beipiaosaurus' quills look, to me, like very elongate versions of those on Sinosauropteryx.

Just a week ago, we could say with a certain confidence that the quills of Psittacosaurus and those of Beipiaosaurus arose convergently. The great phylogenetic distance between the two taxa, with nary a feathered form in between them argued strongly in favor of an independant acquisition of "quills." In fact, they probably had different functions. In Beipiaosaurus, the feathers thickly cover the entire body and were probably used for thermoregulation. Because Psittacosaurus' quills were only present on the dorsal side of the tail, it's likely they had a defensive or display role (or both). But all it takes is one fossil to throw everything paleontologists think they know into question, and one of those fossils was published in this week's issue of the journal Nature.

Behold! Tianyulong confuciusi, a feathered heterodontosaur from China. Now, just to remind you all where heterodontosaurs sit on the dinosaur family tree, a recent reappraisal of basal ornithischians by Butler et al. (2007) suggested that heterodontosaurs represent the basalmost formal group of ornithischians (no more "fabrosaurs" here!). So we've got a ridiculously basal ornithischian with feathers, an incredibly derived ornithischian with "quills," and a whole bunch of coelurosaurs with feathers. But then you've got a whole mess of dinosaurs in between with preserved skin impressions showing scaley, reptilian skin. Does this mean the integument of ornithischians is non-homologous to the integument of saurischians? Well, not necessarily. There may be several factors at play here. "Feathery" integument could be basal to all of the Dinosauria, but may be a juvenile character. The peach fuzz is present on hatchlings but lost upon reaching adulthood. In some dinosaur groups, coelurosaurs and heterodontosaurs, for example, that peach fuzz is retained into adulthood (ontogeny). Or perhaps only small dinosaurs had feathers, or at least those below a certain maximum mass. Large-bodied mammals often have extreme short, fine hair or have gone "bald" entirely. Elephants, hippos and rhinos have all convergently developed hairless bodies, probably in response to the hot temperatures they operate at. Even naked, these animals need to cool off in mud or waterholes. Many dinosaurs became rhino or elephant-sized (or much, much larger), so you wouldn't expect to see feathers on an animal the size of Triceratops or Sauroposeidon. Maybe decorative patches here and there, but certainly not the extent of Sinornithosaurus. Ornithischians could've just used feathers in a different way--Psittacosaurus only retained them on the dorsal surface of the tail, after all, and probably used them for defensive display. The parrot lizard certainly isn't at the theoretical maximum size to still have a full coat of feathers. It's hardly bigger than Beipiaosaurus, which itself is fully fluffed up.

On the other hand, there's a strong preservation bias against feathers. You only get good evidence of feathers on a slab fossil like Archaeopteryx or Tianyulong. You won't find fuzz on a 3D fossil, and that's how larger dinosaurs come out of the ground. Even so, the size assumption does seem to pan out. Skin impressions from a wealth of giant dinosaurs have shown that their skin is pebbled, not feathered. So maybe feathers are basal to all of the Dinosauria, but many groups, including thyreophorans, hadrosaurs, and sauropods secondarily lost their plumage entirely. One thing does seem clear--of all the dinosaur groups where integument of any kind is known, only one small branch of the Theropoda developed true feathers--the kind that gets you up in the air. If the feathers on Psittacosaurus, Tianyulong, and Baipiaosaurus really are homologous, then feather structure remained relatively conservative across the spectrum, and only got the "next stage" in the theropods. Tianyulong's authors note the differences (mostly in cross-sectional shape) between the feathers of the heterodontosaur and the therizinosaur, but these are fairly minor quips. Aside from one being circular and the other being flatter, they look startlingly similar. I would be genuinely surprised if "feathery" integument was not basal to the Dinosauria at this point.

But wait--there's more! Check out those pterosaurs. They all had some kind of fuzz, too. It's usually thought to have arose separately, but what if, just what if, the integument of Sordes 'n' Pals is homologous to the integument of Tianyulong and Baipiaosaurus? That would mean that all ornithodirans, basically everyone from pterosaurs to dinosaurs, was fluffy to some degree. Marasuchus, Silesaurus, nobody's safe. They might've all had feathers.

The fact that all of the Ornithodira could be fluffy has enormous consequences for paleontology. First of all, it probably means that ornithodirans were endothermic. Ectothermic animals, today anyway, don't have hairy or feathery integument. No hairy lizards or feathery turtles, I'm afraid. Interestingly, the one mammal that has reverted to ectothermy, the naked mole-rat, has lost its furry coats--without the ability to generate heat internally, it has no need to try and retain that heat, so the hair disappeared. Naked skin seems to equal ectothermy, and fuzzy skin seems to equal endothermy. That doesn't mean dinosaurs that secondarily lose their feathers reverted to ectothermy. Far from it! The larger an animal gets, the more dangerous a coat of hair or feathers becomes. African elephants don't have mammoth coats of hair because if they did, they'd overheat. They have enough problems maintaining their body temperature at a reasonable constant with all that surface area, thank you very much. I imagine the same problem plagued sauropods, hadrosaurs, and ceratopsians. For those guys, a coat of feathers would've been suicide.

But wait--there's more! Suddenly, dinosaurs who live in Alaska, Russia, and Australia have a way to beat the cold! Now granted, temperatures in Cretaceous Alaska never reached the horrible lows we see today, but ice would've formed in the winters, and snow may have fallen. Australia faced much the same situation, and Siberia probably did, too. Alaska and Siberia were farther north, and Australia was farther south. All this time, paleontologists have been suggesting migration or hibernation for high-latitude dinosaurs, but now that fuzz has come along on ornithischians, little Leaellynasaura suddenly has a way to insulate against those chilly twilight nights. Now, up in Alaska, I'm not saying that larger dinosaurs (like Edmontosaurus and Pachyrhinosaurus) did NOT migrate south, but maybe they adapted to the cold in the same way that Pleistocene megafauna did: grow a thick, lusterus coat of fluff in the winter, and shed most of it in the summer. Of course, skin impressions from Alaskan specimens would help, as would publication of the material coming out of the Colville. Our Pachyrhinosaurus might be a distinct species, but nothing substantial has been published on it.

So there you have it, folks. Feathered heterodontosaurs are ridiculously exciting for a number of reasons. Now, this initial find should be treated with some caution. It's not uncommon for Chinese fossils to be faked somehow, and I'd like to see more ornithischian families discovered with evidence of feathers before the idea of feathers being plesiomorphic for Dinosauria is really cemented. Still, it's one helluva step forward.

*There is increasing doubt, however, that Dilong and Guanlong are ancestral tyrannosaurs. Instead, they may simply represent forms which fall between Ornitholestes and compsognathids. This would actually be helpful, as it would mean the origins of feathers are pushed to the very base of the Coelurosauria.


Traumador said...

Man it is really exciting right now in Dinosaur palaeo!!!

This totally starts filling in holes that have been begging to be filled.

In particular the Polar Dino question. Bell and Snively's paper on migration raised many issues around how smaller polar dinos were surviving, but they didn't have any evidence of feathers in Ornithischians. The Dinosaurs of New Zealand are clear proof that not all Dinos could migrate from the poles and surviving there (as NZ split from Gondwanaland 83mya).

All Dino types having the potential to have feathers makes that sit a lot easier. Though it raises one last interesting family everyone is overlooking...

Ankylosaurs! They along with the Hypsolophodontids are always present in the poles (as in North and South). Picture that?!? A feathered Ankylosaur!!! (specifically Nodosaurs, as we don't have any proper Ankylosaurids in the south... yet anyways?)... Though the armour strikes me as having certain isolating potential. Still image on of them coverd in fuzz TOO!

That overall Archasaur issue bring chills to the spine for sure.

Thomas R. Holtz, Jr. said...

With regards to your footnote: I would say that the "increasing doubt" may be taking a MAJOR U-turn in the next few months... I'm just saying is all...

Sarah Spears said...

What are your thoughts on people considering these feathers on the heterodontosaur merely collagenous fibers, and not feathers? I don't know enough about the discovery to make an argument either way, and of course, that is what some people here at Kansas are saying.

Jerry D. Harris said...

What are your thoughts on people considering these feathers on the heterodontosaur merely collagenous fibers, and not feathers? I don't know enough about the discovery to make an argument either way, and of course, that is what some people here at Kansas are saying.

Without saying that the structures on Tianyulong (or the quill-tailed Psittacosaurus, for that matter) are homologous with "protofeathers" (which is still wholly up in the it were), my limited understanding of collagen fibers is that these things are WAY too long to be collagen fibers in proportion to the size of the animal....aren't they? I also don't know how collagen fibers are oriented within the skin, but if they're oriented perpendicular to the skin surface, then these things would mean the animal has skin that was far thicker than the rest of the body combined...! If they're oriented parallel to the skin surface, wouldn't that make the skin incredibly tough and inflexible?

Zach Armstrong said...

Sarah: There are several reasons why the feather-like integument of Tianyulong could not be collagen.

As Greg Paul said in a post to the Dinosaur Mailing List recently, regarding Tianyulong: "It is not possible for the fibers to represent internal collagen. They are too long, extend much too far from the body even on the tail, and are oriented in exactly the manner of external fur and feathers (sweeping outwards and a little posterior rather than the more irregular, criss-cross pattern expected of collagen). This pattern is repeated on numerous Yixian theropod specimens as well as birds. Nor has it been explained why small dinosaur skin was packed with so much collagen -- they were not spring bodied ichthyosaurs after all. The collagen hypothesis is scientifically deceased unless heterodontosaurs or small theropods with extensive scale coverings show up. "

Furthermore, when one compares the known collagen fiber impressions of ichthyosaurs to this (which has been the primary means of comparison by Theagarten Lingham-Soliar, Alan Feduccia and others), it can definitely be ascertained that Tianyulong's feathers are not collagen. As an aside to that, if we assumed it was collagen, then what are terrestrial bipedal herbivores doing with thick skin layers of a bathypelagic marine animal?! Does that make any sense?! Those who argue for a comparison between ichthyosaur collagen and the feather-like integumentary structures in dinosaurs have no answer, and need to get their head offense.

Zach Armstrong said...

BTW, could anyone send me the paper in which Tianyulong is described? Thanks in advance....

Sarah Spears said...

No offense taken by me! It's not my opinion, but that's all I'm hearing from the VP department at KU (ala Larry Martin and others). I just don't know how to respond.....thank you (and you too, Jerry!) for your insight, that helps clear my understanding.
